Conversational AI: Building Intelligent Voice Agents with VideoSDK

1class AIAgent:
2    """
3    An AI agent that can join video meetings, process audio from participants,
4    and analyze shared screens using OpenAI and Gemini APIs.
5    """
6    def __init__(self, meeting_id: str, authToken: str, name: str):
7        # Set up custom audio track for the agent to speak
8        self.audio_track = CustomAudioStreamTrack(
9            loop=self.loop,
10            handle_interruption=True
11        )
12
13        # Configure meeting settings
14        self.meeting_config = MeetingConfig(
15            name=name,
16            meeting_id=meeting_id,
17            token=authToken,
18            mic_enabled=True,
19            webcam_enabled=False,
20            custom_microphone_audio_track=self.audio_track,
21        )
22
23        # Initialize models for intelligence
24        self.vision_model = genai.GenerativeModel('gemini-1.5-flash')
25        self.intelligence = OpenAIIntelligence(
26            loop=self.loop,
27            api_key=openai_api_key,
28            base_url="api.openai.com",
29            audio_track=self.audio_track,
30        )
31

1async def join(self):
2    """Join the meeting asynchronously."""
3    await self.agent.async_join()
4
5# In main.py - how we expose this as an API endpoint
6@app.post("/join-player")
7async def join_player(req: MeetingReqConfig, bg_tasks: BackgroundTasks):
8    bg_tasks.add_task(server_operations, req)
9    return {"message": "AI agent joined"}
10

1async def add_audio_listener(self, stream: Stream, peer_name: str):
2    """Process audio from a participant and send to OpenAI for transcription."""
3    while True:
4        # Get audio frame from VideoSDK stream
5        frame = await stream.track.recv()
6        audio_data = frame.to_ndarray()[0]
7
8        # Convert to float and process for optimal quality
9        audio_data_float = (audio_data.astype(np.float32) / np.iinfo(np.int16).max)
10        audio_mono = librosa.to_mono(audio_data_float.T)
11        audio_resampled = librosa.resample(audio_mono, orig_sr=48000, target_sr=16000)
12
13        # Convert to PCM for OpenAI
14        pcm_frame = ((audio_resampled * np.iinfo(np.int16).max).astype(np.int16).tobytes())
15
16        # Send to OpenAI for processing
17        await self.intelligence.send_audio_data(pcm_frame)
18

1async def handle_function_call(self, function_call):
2    """Handle screen analysis requests from the LLM."""
3    if function_call.name == "analyze_screen":
4        if not self.latest_frame:
5            return "No screen content available"
6
7        # Convert frame to image
8        image_data = self.latest_frame.to_ndarray()
9        image = Image.fromarray(image_data)
10
11        # Request analysis from Gemini
12        response = await self.loop.run_in_executor(
13            None,
14            lambda: self.vision_model.generate_content([
15                "Analyze this screen to help user. Focus on relevant UI elements, text, code, and context.",
16                image
17            ])
18        )
19        return response.text
20

1# Define tool for screen analysis
2screen_tool = {
3    "type": "function",
4    "name": "analyze_screen",
5    "description": "Analyze current screen content when user asks for help with visible elements",
6    "parameters": {"type": "object", "properties": {}}
7}
8
9# Initialize OpenAI intelligence
10self.intelligence = OpenAIIntelligence(
11    loop=self.loop,
12    api_key=openai_api_key,
13    base_url="api.openai.com",
14    input_audio_transcription=InputAudioTranscription(model="whisper-1"),
15    tools=[screen_tool],
16    audio_track=self.audio_track,
17    handle_function_call=self.handle_function_call,
18)
19

1class CustomAudioStreamTrack(CustomAudioTrack):
2    """Custom audio track for streaming synthesized speech in a video meeting."""
3
4    def add_new_bytes(self, audio_data_stream: Iterator[bytes]):
5        """Add new audio data to be processed and played."""
6        await self._process_audio_task_queue.put(audio_data_stream)
7
8    async def recv(self) -> AudioFrame:
9        """Receive the next audio frame for streaming."""
10        # Get frame from buffer or create silent frame if buffer is empty
11        if len(self.frame_buffer) > 0:
12            frame = self.frame_buffer.pop(0)
13        else:
14            # Create a silent frame when nothing to say
15            frame = AudioFrame(format="s16", layout="mono", samples=self.samples)
16            for p in frame.planes:
17                p.update(bytes(p.buffer_size))
18
19        # Set frame properties and return
20        frame.pts = pts
21        frame.time_base = time_base
22        frame.sample_rate = self.sample_rate
23        return frame
24

1# Set up event handlers for meeting participants
2def on_participant_joined(self, participant: Participant):
3    """Handler for when a participant joins the meeting."""
4    peer_name = participant.display_name
5    print("Participant joined:", peer_name)
6
7    # Set instructions for the AI assistant
8    intelligence_instructions = """
9    You are an AI meeting assistant. Follow these rules:
10    1. Use analyze_screen tool when user asks about:
11    - Visible UI elements
12    - On-screen content
13    - Application help
14    - Workflow guidance
15    2. Keep responses under 2 sentences
16    3. Always acknowledge requests first
17    """
18
19    # Update OpenAI with instructions
20    asyncio.create_task(self.intelligence.update_session_instructions(intelligence_instructions))
21
22    # Set up event handlers for the participant
23    participant.add_event_listener(
24        ParticipantHandler(
25            participant_id=participant.id,
26            on_stream_enabled=on_stream_enabled,
27            on_stream_disabled=on_stream_disabled
28        )
29    )
30

1async def handle_function_call(self, function_call):
2    """Handle function calls from OpenAI, particularly for screen analysis."""
3    if function_call.name == "analyze_screen":
4        if not self.latest_frame:
5            return "No screen content available"
6
7        # Convert frame to image
8        image_data = self.latest_frame.to_ndarray()
9        image = Image.fromarray(image_data)
10
11        try:
12            # Request code-specific analysis from Gemini
13            response = await self.loop.run_in_executor(
14                None,
15                lambda: self.vision_model.generate_content([
16                    "Analyze this code to help the developer. Identify bugs, suggest improvements, and explain complex patterns.",
17                    image
18                ])
19            )
20            return response.text
21        except Exception as e:
22            return f"Analysis error: {str(e)}"
23

1# Main.py API endpoint for tech support
2@app.post("/start-support-session")
3async def start_support_session(req: SupportSessionConfig, bg_tasks: BackgroundTasks):
4    # Create a new meeting for the support session
5    meeting_id = create_new_meeting_id()
6
7    # Configure AI agent with tech support instructions
8    support_instructions = """
9    You are a technical support specialist. When users share their screen:
10    1. Identify the application or system they're using
11    2. Look for error messages or visual issues
12    3. Provide step-by-step troubleshooting guidance
13    4. Be patient and ask clarifying questions
14    """
15
16    # Start the AI agent in the background
17    bg_tasks.add_task(
18        start_support_agent,
19        meeting_id=meeting_id,
20        token=req.token,
21        instructions=support_instructions
22    )
23
24    # Return meeting details for the user to join
25    return {"meeting_id": meeting_id, "join_url": f"https://meet.example.com/{meeting_id}"}
26

1# In the AI agent class
2def configure_as_tutor(self, subject_area):
3    """Configure the AI agent to act as a tutor for a specific subject."""
4    tutor_instructions = f"""
5    You are a patient, helpful tutor specializing in {subject_area}.
6    When students share their work:
7    1. Analyze their approach and identify misconceptions
8    2. Provide encouraging feedback on correct steps
9    3. Ask Socratic questions to guide their thinking
10    4. Explain concepts clearly with examples
11    5. Adapt to their learning style and pace
12    """
13
14    asyncio.create_task(self.intelligence.update_session_instructions(tutor_instructions))
15
16    # Add specialized tools for this subject
17    if subject_area == "programming":
18        self.add_code_execution_tool()
19    elif subject_area == "mathematics":
20        self.add_equation_solver_tool()
21

1├── agent/               # AI agent implementation
2│   ├── ai_agent.py      # Main agent class
3│   └── audio_stream_track.py  # Custom audio track
4├── intelligence/        # AI intelligence components
5│   └── openai/          # OpenAI integration
6│       └── openai_intelligence.py  # OpenAI client
7├── rtc/                 # Real-time communication handlers
8│   └── videosdk/        # VideoSDK event handlers
9├── utils/               # Utility functions and structures
10└── main.py              # API endpoints and server setup
11

1class CustomAudioStreamTrack(CustomAudioTrack):
2    """
3    A custom implementation of an audio track for streaming audio in a video meeting.
4    This class provides functionality to buffer audio data, process it in chunks,
5    and deliver it in a continuous stream for real-time communication.
6    """
7    def __init__(self, loop, handle_interruption: Optional[bool] = True):
8        super().__init__()
9        self.loop = loop
10        self.frame_buffer = []  # Buffer to hold audio frames ready to be sent
11        self.audio_data_buffer = bytearray()  # Raw audio data buffer
12        self.sample_rate = 24000  # Audio sample rate in Hz
13        self.channels = 1  # Mono audio
14
15        # Set up audio processing thread
16        self._process_audio_thread = threading.Thread(target=self.run_process_audio)
17        self._process_audio_thread.daemon = True
18        self._process_audio_thread.start()
19

1class OpenAIIntelligence:
2    """
3    A class to handle real-time communication with OpenAI's streaming API.
4    """
5    def __init__(
6        self,
7        loop: AbstractEventLoop,
8        api_key,
9        model: str = "gpt-4o-realtime-preview-2024-10-01",
10        instructions="""\
11            Actively listen to the user's questions and provide concise, relevant responses.
12            Acknowledge the user's intent before answering. Keep responses under 2 sentences.\
13        """,
14        base_url: str = "api.openai.com",
15        tools: List[Dict[str, Union[str, any]]] = [],
16        audio_track: CustomAudioStreamTrack = None,
17    ):
18        # Initialize configuration
19        self.model = model
20        self.loop = loop
21        self.api_key = api_key
22        self.instructions = instructions
23        self.tools = tools
24        self.audio_track = audio_track
25
26        # WebSocket for real-time communication
27        self.ws = None
28        self.connected_event = asyncio.Event()
29

1from fastapi import FastAPI, BackgroundTasks
2from pydantic import BaseModel
3
4app = FastAPI()
5
6class MeetingReqConfig(BaseModel):
7    meeting_id: str
8    token: str
9
10async def server_operations(req:MeetingReqConfig):
11    # Create and start the AI agent
12    global ai_agent
13    ai_agent = AIAgent(req.meeting_id, req.token, "AI")
14
15    try:
16        await ai_agent.join()
17        while True:
18            await asyncio.sleep(1)
19    except Exception as ex:
20        print(f"[ERROR]: either joining or running bg tasks: {ex}")
21    finally:
22        ai_agent.leave()
23
24@app.post("/join-player")
25async def join_player(req: MeetingReqConfig, bg_tasks: BackgroundTasks):
26    bg_tasks.add_task(server_operations, req)
27    return {"message": "AI agent joined"}
28

1# Configure meeting settings
2self.meeting_config = MeetingConfig(
3    name=name,
4    meeting_id=meeting_id,
5    token=authToken,
6    mic_enabled=True,
7    webcam_enabled=False,
8    custom_microphone_audio_track=self.audio_track,
9)
10
11# Initialize the meeting agent
12self.agent = VideoSDK.init_meeting(**self.meeting_config)
13
14# Add event listeners for meeting events
15self.agent.add_event_listener(
16    MeetingHandler(
17        on_meeting_joined=self.on_meeting_joined,
18        on_meeting_left=self.on_meeting_left,
19        on_participant_joined=self.on_participant_joined,
20        on_participant_left=self.on_participant_left,
21    ))
22

1# Convert to float for processing
2audio_data_float = (audio_data.astype(np.float32) / np.iinfo(np.int16).max)
3
4# Convert to mono and resample to 16kHz (required by Whisper)
5audio_mono = librosa.to_mono(audio_data_float.T)
6audio_resampled = librosa.resample(
7    audio_mono, orig_sr=48000, target_sr=16000
8)
9

1intelligence_instructions = """
2You are an AI meeting assistant. Follow these rules:
31. Use analyze_screen tool when user asks about:
4   - Visible UI elements
5   - On-screen content
6   - Application help
7   - Workflow guidance
82. Keep responses under 2 sentences
93. Always acknowledge requests first
10"""
11
12await self.intelligence.update_session_instructions(intelligence_instructions)
13

1async def handle_function_call(self, function_call):
2    """Handle function calls from OpenAI, particularly for screen analysis."""
3    if function_call.name == "analyze_screen":
4        if not self.latest_frame:
5            return "No screen content available"
6
7        try:
8            # Request analysis from Gemini
9            response = await self.loop.run_in_executor(
10                None,
11                lambda: self.vision_model.generate_content([
12                    "Analyze this screen to help user. Focus on relevant UI elements, text, code, and context.",
13                    image
14                ])
15            )
16            return response.text
17        except Exception as e:
18            return f"Analysis error: {str(e)}"
19    return "Unknown command"
20

1# Use small buffer sizes for more responsive audio
2self.samples = int(AUDIO_PTIME * self.sample_rate)  # 20ms chunks for low latency
3self.chunk_size = int(self.samples * self.channels * self.sample_width)
4
5# Process audio in a separate thread to avoid blocking
6self._process_audio_thread = threading.Thread(target=self.run_process_audio)
7self._process_audio_thread.daemon = True
8self._process_audio_thread.start()
9

1class OpenAIIntelligence:
2    def __init__(self, ...):
3        # Session parameters maintain context
4        self.session_update_params = SessionUpdateParams(
5            model=self.model,
6            instructions=self.instructions,
7            input_audio_format=AudioFormats.PCM16,
8            output_audio_format=AudioFormats.PCM16,
9            temperature=self.temperature,
10            voice=self.voice,
11            tool_choice="auto",
12            tools=self.tools,
13            turn_detection=self.turn_detection,
14            modalities=self.modalities,
15            max_response_output_tokens=self.max_response_output_tokens,
16            input_audio_transcription=self.input_audio_transcription,
17        )
18

1def interrupt(self):
2    """Interrupt the current audio playback."""
3    length = len(self.frame_buffer)
4    self.frame_buffer.clear()  # Clear all pending audio frames
5
6    # Empty the task queue to stop processing more audio
7    while not self._process_audio_task_queue.empty():
8        self.skip_next_chunk = True
9        self._process_audio_task_queue.get_nowait()
10        self._process_audio_task_queue.task_done()
11

1async def cleanup(self):
2    """Cleanup resources when the agent is destroyed."""
3    # Cancel all running tasks
4    for task in self.audio_listener_tasks.values():
5        if task and not task.done():
6            task.cancel()
7    for task in self.screenshare_listener_tasks.values():
8        if task and not task.done():
9            task.cancel()
10
11    # Clear the queues
12    self.frame_queue.clear()
13
14    # Leave the meeting
15    self.leave()
16

1def on_participant_joined(self, participant: Participant):
2    def on_stream_enabled(stream: Stream):
3        """Handler for when a participant enables a stream."""
4        if stream.kind == "audio":
5            # Start processing audio
6            self.audio_listener_tasks[stream.id] = self.loop.create_task(
7                self.add_audio_listener(stream, peer_name)
8            )
9        elif stream.kind == "share":
10            # Start processing screen share
11            self.screenshare_listener_tasks[stream.id] = self.loop.create_task(
12                self.add_screenshare_listener(stream, peer_name)
13            )
14

1# Initialize the meeting agent with multiple AI models
2self.vision_model = genai.GenerativeModel('gemini-1.5-flash')  # For visual understanding
3self.intelligence = OpenAIIntelligence(...)  # For conversation
4self.document_analyzer = DocumentAnalysisModel(...)  # For parsing documents
5

1# Configuration for edge deployment
2edge_config = {
3    "use_local_whisper": True,  # Use local speech recognition
4    "use_local_tts": True,      # Use local text-to-speech
5    "fallback_to_cloud": True   # Fall back to cloud for complex queries
6}
7

1# Fine-tune the AI for a specific domain
2async def specialize_for_domain(self, domain_data, domain_name):
3    """Adapt the AI to a specific knowledge domain."""
4    domain_instructions = f"""
5    You are specialized in {domain_name}. Use the following knowledge:
6    {domain_data}
7    When answering questions about {domain_name}, refer to this specialized knowledge.
8    """
9    await self.intelligence.update_session_instructions(domain_instructions)
10
